- Place of Origin: Shandong, China (Mainland)
- Brand Name: Smartech
- Model Number: Leading-1490
Performance Features
1 Optional: flat worktable, honeycomb worktable, aluminium bar worktable and so on.
2 USB data interface, can work offline and convenient for mass production.
3 With the drawer and the funnel design for collecting remnant material, it is convenient to use.
4 High quality water cooler, protect stable radiation and prolong the lift-span of laser
Product Information
Cutting Area | 1400x900mm |
Laser Power | 80W/100W |
Laser Type | CO2 Laser tube |
Cutting Speed | 0-50000mm/min |
Reposition Accuracy | 0.01mm |
Power Supply | 220V/50HZ or 110V/60HZ |
Operation Temperature | 0 - 45°C |
Operation Humidity | 5-95% |
Min. Shaping Character | English 1.0x 1.0mm |
Graphic Format Supported | PLT,AI,DXF,BMP,DST.etc. |
Software Supported | CorelDraw, Photoshop, AutoCAD, Tajima |
Driving System | 3 Phases Stepper Motor |
Cooling Mode | Water-cooling and Protection System |
Equipment Dimensions | 1960*1310*1120mm |
Net Weight/Gross Weight | 500KGS/580KGS |
Shipping Dimensions | 2060*1410*1300mm |
