- Place of Origin: Shandong, China (Mainland)
- Brand Name: Smartech
- Model Number: Leading-9015
Features
1) the machine operates smoothly and accurately bearing heavy load and long working life.
2)Advanced structure design and integral cast frame make performance stably and durably.
3)Adopting the transmission way of ball screw to make sure processing accuracy.
4)Cabinet-structure gantry with good performance against pressure and deformation.
5)Adopted advanced NC STUDIO control system
6)Separated control box,convinent to control the work process.
Technical Specifications:
X,Y Working area | 900mmx1500mm |
Z Working area | >120mm |
Table size | 1100mmx1800mm |
Resolution ratio | 0.005mm |
Reposition precision | 0.05mm |
Power(spindle is not included) | 1000W |
Command | G CODE |
Max travelling speed | 6m/min |
Max speed | 8.8m/min |
Work voltage | AC380V/50Hz |
Spindle power | 3KW |
Spindle rotating speed | 0-24000rpm/min |
Drive motor | Stepper |
